| total width | ~525mm |
| width of factual covering | 490mm |
| a roof tile module length | 35mm |
| maximum sheet length | any |
| sheet metal thickness | 0,5mm |
Burden material

Standard polyester/shine thickness 0,5/0,7
Coating class:
The oldest and very popular organic coating of 25 µm, galvanized 275 g/m2. The surface is smooth, uniform with a specific gloss. It is mostly used in house building and industrial building on roofs and elevations. Available in many colours from the RAL palette. Due to a wide selection of colours and affordable price it is very popular.Warranty period for 10 years.
| Sheet metal thickness | 0,5; 0,7 |
| Coating thickness | Surface coating:25 microns Lower coating:7 microns |
| Category of resistance to corrosion | RC3 |
| Category of resistance to ultraviolet radiation | RUV2 |
| Finishing | Smooth |
| Resistance to cracking while crushing | <= 3 T |
| Resistance to scratching (Clemen) | >= 2 kg |
| Fire-resistance classification | A1 |
RAL 8017
RAL 8019
RAL 7016
RAL 7024
RAL 6005
RAL 6020
RAL 8004
RAL 3011
RAL 3005
RAL 3009
RAL 3000
RAL 5010
RAL 9010
RAL 9002
RAL 9006

Polyester mat
Coating class:
Improved version of standard polyester. Thickness of organic coating is 35 µm, galvanization minimum 275 g/m2. The coating is almost without any gloss and is described as coarse grained mat. The surface is slightly rough, porous. Due to such a surface, it resembles a roof tile from a distance. The polyester mat surface is very elastic with high anticorrosion characteristics and is resistant to discolouration caused by sunlight. It is highly respected in housing.Warranty period for 10 years.
| Sheet metal thickness | 0,5 |
| Coating thickness | Surface coating:35 microns Lower coating:7 microns |
| Category of resistance to corrosion | RC3 |
| Category of resistance to ultraviolet radiation | RUV3 |
| Finishing | Mat |
| Resistance to cracking while crushing | <= 2 T |
| Resistance to scratching (Clemen) | >= 1,5 kg |
| Fire-resistance classification | F |
RAL 8017
RAL 8019
RAL 8004
RAL 3009
RAL 6020
RAL 7024
RAL 7016
RAL 9005

SHIMOCO
Coating class:
Modern and very durable polyester coating. Thickness of organic coating is 80 µm, galvanization Z 275 g/m2. The surface has got a uniform pattern structure (with preserving aesthetic of grain) which beautifully reflects light. The SHIMOCO system formula guarantees best protection against UV and corrosion. It provides maximum flexibility and durability. The highest quality resistance to scratching and grinding. The coating fabricated by Italian concern MARCEGAGLIA.SHIMOCO is an amazing choice. High quality goes along with reasonable price. The product may be used both in housing and industrial constructions.
Warranty period up to 30 years.
| Sheet metal thickness | 0,5 |
| Coating thickness | Surface coating:80 microns Lower coating:7 microns |
| Category of resistance to corrosion | RC5 |
| Category of resistance to ultraviolet radiation | RUV4 |
| Finishing | Uniform structure pattern (aesthetic value) |
| Resistance to cracking while crushing | < 2 T |
| Resistance to scratching (Clemen) | >= 2 kg |
| Fire-resistance classification | F |
RAL 3005
RAL 3009
RAL 3011
RAL 6020
RAL 7016
RAL 8004
RAL 8017
RAL 8019
RAL 9005

Granite® HDX
Coating class:
A kind of organic polyurethane coating with polyamide granules. Thickness of the surface organic coating is 55 µm, galvanization 275 g/m2. The parameters make the product very durable and resistant to any external conditions, like weather conditions or mechanical damage. The surface is slightly rough, grainy. Metal sheet’s producer is a steelwork concern ArcelorMittal, and due to a multi-year experience in the production of lots of coated steels, in terms of technology and aesthetics, Granite® HDX is the best product from the Granite® series. It is a perfect solution intended for use in aggressive and demanding environments:
- cold and moist environment
- coastal areas (to 20km from the shoreline)
- sunlit areas of high level of UV radiation
- industrial an polluted areas
Warranty period for 30 years.
| Sheet metal thickness | 0,5; 0,7 |
| Coating thickness | Surface coating:55 microns Lower coating:7 microns |
| Category of resistance to corrosion | RC5 |
| Category of resistance to ultraviolet radiation | RUV4 |
| Finishing | Coating with a granular structure |
| Resistance to cracking while crushing | <= 1,5 T |
| Resistance to scratching (Clemen) | >= 3 kg |
| Fire-resistance classification | F |
RAL 8017
RAL 7016
Wood-like
Coating class:
A modern and popular organic coating with a thickness of 25 µm, Aluzinc coating with a coating weight of 70 g/m2. The surface has a wood-like structure with visible strips and grain patterns. It is most commonly used in residential and industrial construction, on façades and fences. It is often used to produce slats, soffits, or façade elements that replace traditional wood. It ensures long-term durability without the need for costly maintenance.Warranty period 10 years.
| Sheet metal thickness | 0,41 |
| Coating thickness |
Surface coating: 25 microns Lower coating: 7 microns – primer layer |
| Category of resistance to corrosion | RC3 |
| Category of resistance to ultraviolet radiation | RUV2 |
| Finishing | Smooth |
| Resistance to cracking while crushing | <= 3 T |
| Resistance to scratching (Clemen) | >= 2 kg |
| Fire-resistance classification | A1 |
